The LOIP LH-200 round bottom flask heater is used for heating liquids and solids, synthesis and distillation, control of the fractional composition, determination of the water content according to current standards and other tasks involving heating at temperatures up to +600°C.
Model LOIP LH-250 is designed for heating round bottom flasks with a volume of 250 to 1000 ml.
Design features:
LOIP-LH-200 instrument heating spirals, pressed into a stainless steel shell, are protected against spillage of working fluid and securely insulated from the housing.
The heating element, which has a minimum inertia of operation, allows heating up to +600°C.
Stainless steel housing.
The high radiant heat of the heater allows flasks of different volumes and shapes to be used with one LOIP-LH-200.
Very precise temperature maintenance due to proportional-integral thermostat with feedback to the control thermocouple.
Cell for mounting tripod stands* is located on the body of the flask heater.
* - tripod racks and fasteners are not included.
Technical characteristics:
Volume of heated flask, ml 250-1000
Maximal heating temperature, °С 600
Dimensions, mm 170x230x160
Power, Watt 650
Weight, kg 3
